FD-600-N2 – Nitrogen Gas Detector | Analyzer for N2 Leaks

Brand: FORENSICS DETECTORS
Model: FD-600-N2
User Manual: Click Here

Features:

• 🎆 USES: Used to detect Nitrogen Gas Leaks via oxygen depletion. High-quality electrochemical oxygen sensor.
• 🌈 COLOR: Color screen and graph functions allow for easy and intuitive operation.
• 📲 DATA LOGGING: USB recharging and real-time data acquisition. Arrives with silicone tubing, a stainless probe, and a filter.
• 💪 STRONG: Robust design constructed with high-strength ABS and anti-slip grip rubber. Water, dust, and explosion resistance exceeding Exib IIB T4 Gb.
• 🕵️ TRUSTWORTHY: 1-year limited warranty. Arrives with a signed and dated calibration certificate.

Details: A Nitrogen Gas Detector is used to detect a leak in Nitrogen by measuring oxygen concentration. When storing nitrogen, or trying to find a nitrogen leak, it is best to use an Oxygen Analyzer to find a reduced oxygen purity that indicates a nitrogen leak.  The FORENSICS nitrogen analyzer (which is actually an oxygen analyzer) is an excellent option for those that would like to find any displaced oxygen due to nitrogen. This nitrogen detector is perfect for checking leaks in nitrogen purge systems, nitrogen containment, nitrogen in a pressurized flush situation, pipe purging, N2 leak analysis, and other applications. The oxygen gas analyzer measures the oxygen content in the weld chamber down to 0.01% (100 ppm). Based on our industrial analyzer platform, the built-in pump is easy to use, light, and very portable. The analyzer has a color screen, large digits, and on-screen real-time graphing. The detector is built using an advanced electrochemical oxygen sensor. The internal 32-bit microprocessor allows for user calibration, ON/OFF flow, and test control.

Included: O2 analyzer and magnet back, user manual, certified calibration certificate, USB charging cable, charger, 1 x 3-inch stainless needle probe, and 2 ft silicone tubing.

Calibration Options:
Calibration Service by Forensics Detectors
Calibration Tutorial (DIY)

Calibration Kit Items (DIY sold separately):
Calibration T-piece & Tubing
Calibration Gas (N2)
Calibration Gas Regulator (C10)
Bump Gas (N2)

Other Accessories (sold separately):
Gas Sensor Replacement (O2)
Gas Detector Waterproof Case
Gas Detector Stand
Air Gas Sample Probe
Tubing

Specifications

Oxygen (O2) Detection: 0 – 30% with 0.01% resolution
Error: ≤ ± 1%
Response Time: < 30 seconds
Store / Operating Temp: 0°F – 122°F
Store / Operating Humidity: <95%RH
Battery: DC 3.7V Li-on battery, 3200 mAh
Gas Sensor Type: Electrochemical Gas Sensor
Gas Sensor Life: 2 – 3 years
Recommended Calibration Period: 12 months
Explosion-Proof Grade: ATEX certified Ex ib IIC T4 Gb
Weight: 14 oz
Dimensions: 5.1 in × 2.6 in x 1.2 in
Charge Time: 4 hours
Operating Time: > 10 hours
Pump Rate: 0.1 – 0.3 LPM (100 – 300 cc/min)
Alarm: LED
Calibration Location (USA): Los Angeles, California, USA
Calibration Standard (USA): USA NIST Traceable Gas Source
Calibration Location (Europe): Athens, Greece
Calibration Standard (Europe): European NPL Traceable Gas Source
